UF-B 2 Conductor with Ground

R7295D

Regency’s UF – B jacketed cable is manufactured for the purpose of direct burial power wire applications in accordance with the National Electric Code.

Conductor construction is soft drawn bare copper meeting the requirements of ASTM Specification B-3. Gauge sizes 14 and 10 are solid copper conductors. Sizes 8 thru 6 are stranded conductors. All ground wires are solid.

The insulation is a color coded THWN-2 type for wet, dry or corrosive applications of up to 600 volts and conductor temperatures up to 60 C. The outer jacket is a sunlight resistant, high quality polyvinylchloride (PVC).

The UF – B 2 Conductor w/ Ground jacketed cable is constructed in accordance with Underwriters Laboratories, Inc. standards UL83 and UL493.

Construction

  • Conductor: Soft drawn bare copper (ASTM Spec. B-3). Solid (14 awg and 10 awg) Stranded (8 awg to 6 awg) Solid ground
  • Insulation: Polyvinylchloride (PVC) with a nylon sheath
  • Outer Jacket: Polyvinylchloride (PVC)
  • Temperature: 60º C
  • Voltage: 600 Volts
DOWNLOAD PDF

Conductor
Size (AWG)StrandingGround SizeStandard Packaging Option
Conductor
Size (AWG)
14
Stranding
Solid
Ground Size
14
Header
1X500’, 1X1000’
Conductor
Size (AWG)
12
Stranding
Solid
Ground Size
12
Header
1X500’, 1X1000’
Conductor
Size (AWG)
10
Stranding
Solid
Ground Size
10
Header
1X500’, 1X1000’
Conductor
Size (AWG)
8
Stranding
Stranded
Ground Size
10
Header
1X500’, 1X1000’
Conductor
Size (AWG)
6
Stranding
Stranded
Ground Size
10
Header
1X500’, 1X1000’
